Ring lock horizontal diagonal level diagonal brace for ring lock
scaffold system with hot dip galvanized
Introduction and features for ring lock horizontal diagonal
Scaffolding ring lock horizontal diagonal is one of the brace in
ring lock system, it can fix the whole system and reinforce loading
capacity, are the same as ring lock ledger, but different sizes,
the ring lock scaffolding system has the following features:
1. Safer and more stable than other scaffold system.
2. With hot dip galvanized finish can expand life span to 20 years.
3. Easy for erection and dismantlement, convenient and can save
much time & labor.
4. Compared with cuplock can save 1/3 steel around, save time &
time & labor.
5. With good look in project image
Dimension for ring lock horizontal diagonal
| Name | O.D(mm) | Thickness(mm) | Length(mm) | Finish | Weight(kg) |
| Ring lock horizontal diagonal | 48.3 | 3.00 | 1200*1500 | HDG, painted | 7.02 |
| Ring lock horizontal diagonal | 48.3 | 3.00 | 1200*1800 | HDG, painted | 7.85 |
| Ring lock horizontal diagonal | 48.3 | 3.00 | 1500*1800 | HDG, painted | 8.45 |
| Ring lock horizontal diagonal | 48.3 | 3.00 | 1800*1800 | HDG, painted | 9.15 |
| Ring lock horizontal diagonal | 48.3 | 2.75 | 1200*1500 | HDG, painted | 6.55 |
| Ring lock horizontal diagonal | 48.3 | 2.75 | 1200*1800 | HDG, painted | 7.31 |
| Ring lock horizontal diagonal | 48.3 | 2.75 | 1500*1800 | HDG, painted | 7.88 |
| Ring lock horizontal diagonal | 48.3 | 2.75 | 1800*1800 | HDG, painted | 8.52 |
Remarks: we can do any sizes as the requirement of customers.
How to produce one ring lock horizontal diagonal?
Remarks: ring lock horizontal diagonal has the same process as ring lock
ledger
Package and loading details for ring lock horizontal diagonal
Normally, we pack ring lock horizontal diagonal as like ring lock
ledgers:
Option 1. Bundles package: with steel belt to fix and load by forklift, this type of pacakge
can save space.
Option 2. Iron pallet or make products themselves to a structure frame, then put all products in it, this kind of package will be very
nice looking, but cannot save much space.
Dear customer, we can also pack these products as your request.
Certification for ring lock scaffolding system
Application for ring lock horizontal diagonal
Scaffolding ring lock horizontal diagonal, as one part of ring lock
scaffolding system, can also used in many engineering projects,
such as:
#1. Brigde building
#2. Tunnel
#3. Viaduct
#4. Water tower
#5. Hydropower plant
#6. Oil refinery
#7. Stage set-up
#8. Sports stadium
#9. Workshop building
#10. Civil construction and so on
